Fanless design, quiet, energy-saving and clean, which reduces the possibility of cross-infection.
All-round monitor for adult, pediatric and neonate.
With standard interface, OxyCRG, trend chard, big character interface and view bed, convenient to observe.
Waveform, parameter color and location can be set optionally.
Operation mode: keys and buttons.
Display up to 8-channel waveform on one screen.
Display 7-lead ECG waveform on one screen, and with ECG step function.
Adopt digital SpO2 technology, anti-motion and anti-ambient light interference, and measurement can be performed under the circumstance of weak filling.
HRV analysis function.
NIBP measurement mode: Manual/AUTO/Continuous, storage for 4800-group NIBP data.
Review for 71 alarm events of all parameters and 60 arrhythmia alarm events.
Drug concentration calculation and titration table functions.
Print trend table data with one-key.
AC/DC, built-in rechargeable lithium battery achieve uninterrupted monitoring.
Anti-high frequency surgical unit, defibrillation-proof(special leads are necessary)
Options
Invasive Blood Pressure (IBP)
Carbon dioxide (CO2) Module
Masimo SpO2 Module
Thermal Printer
Touch Function
Display
Device 12.1 in. Color TFT, 3 LED
Messages
8 Waveforms Maximum
1 Alarm LED (Yellow/Red)
1 Power LED (Green)
1 Battery Charge LED ( Yellow)
3 Sound Mode corresponding Alarm Mode
ECG
Lead Mode 5 Leads ( R, L, F, N, C or RA, LA, LL, RL, V)
Lead selection I, II, III, aVR, aVL, aVF, V,
Waveform 2 CH
Lead mode 3 Leads ( R, L, F or RA, LA, LL)
Lead selection I, II, III,
Waveform 1 ch
Gain ´2.5mm/mV, ´5.0mm/mV, ´10mm/mV, ´20mm/mV
HR Measuring and Alarm Range
ADU 15~300 bpm
PED/NEO 15~350 bpm
Accuracy ±1% or ±1bpm, which great
Resolution 1 bpm
Sensitivity > 200 uV P-P
Differential Input Impedance > 5 MΩ
CMRR
Monitor ≥ 100dB
Operation ≥ 100 dB
Diagnosis ≥60dB
lectrode offset potential ±300mV
Leakage Current < 10 uA
Baseline Recovery ≤5 s After Defi.
ECG Signal Range ±8 mV (Vp-p)
Bandwidth
Surgery 1~20 HZ(+0.4dB,-3dB)
Monitor 0.5Hz~40Hz(+0.4dB,-3dB)
Diagnostic 0.05Hz~75Hz(+0.4dB,-3dB);76Hz~150Hz(+0.4dB,-4.5dB)
Calibration Signal 1 mV (Vp-p), ±5% Accuracy
ST Measure and Alarm Range -2.0 ~ +2.0mV
Accuracy
-0.8~+0.8mv ±0.04mv or ±10% which is greater
Other unspecified
ARR Detecting
Type ASYSTOLE, VFIB/VTAC, COUPLET, BIGEMINY, TRIGEMINY, R ON T, VT>2, PVC, TACHY, BRADY, MISSED BEATS, PNP, PNC
Alarm Available
Review Available
RESPIRATION
Method Impedance between R-F(RA-LL)
Differential Input Impedance >2.5 MΩ
Measuring Impedance Range: 0.3~5.0Ω
Base line Impedance Range: 0.1 KΩ– 2.5 KΩ
Bandwidth 0.3 ~ 2.5 Hz
RR Measuring and Alarm Range
ADU 0~120 rpm
PED/NEO 0~150 rpm
Resolution 1 rpm
Accuracy ±2 rpm
Apnea Alarm 10 ~ 40 S
NIBP
Method Oscillometric
Mode Manual, Auto, STAT
Measuring Interval in AUTO Mode 1, 2, 3, 4, 5, 10, 15, 30, 60, 90,120,180,240,480Min
Measuring Period in STAT Mode 5 Min
Alarm Type SYS, DIA, MEAN
Measuring and alarm Range
Adult Mode
SYS 40 ~ 270 mmHg
DIA 10 ~ 215 mmHg
MEAN 20 ~ 235 mmHg
Pediatric Mode
SYS 40 ~ 200 mmHg
DIA 10 ~ 150 mmHg
MEAN 20 ~ 165 mmHg
Neonatal Mode
SYS 40 ~ 135 mmHg
DIA 10 ~ 100 mmHg
MEAN 20 ~ 110 mmHg
Resolution
Pressure 1mmHg
Accuracy
Pressure
Mean error ±5mmHg
Maximum Standard deviation 8mmHg
Software Overpressure Protection
Adult Mode 297±3 mmHg
Pediatric Mode 240±3 mmHg
Neonatal Mode 147±3 mmHg
SpO2
Measuring Range 0 ~ 100 %
Alarm Range 0 ~ 100 %
Resolution 1 %
Accuracy
70% ~ 100% ±2 %
0% ~ 69% unspecified
Actualization interval about 1Sec.
Alarm Delay 10 Sec.
Pulse Rate
Measuring and Alarm Range 30~250bpm
Resolution 1bpm
Accuracy ±2bpm
TEMPERATURE
Channel 2
Measuring and Alarm Range 0 ~ 50 °C
Resolution 0.1°C
Accuracy ±0.1°C
Actualization interval about 1 Sec.
Average Time Constant < 10 Sec.
IBP
Channel 2
Label ART, PA, CVP, RAP, LAP, ICP, P1, P2
Measuring and Alarm Range -10~300mmHg
Press Sensor
Sensitivity 5 uV/V/mmHg
Impedance 300-3000Ω
Resolution 1mmHg
Accuracy ±2% or 1mmHg which great
Actualization Interval about 1 Sec
EtCO2
Method Infra-red Absorption Technique
Measuring mode MainStream and Sidestream
Side-stream mode sampling gas flow rate
50ml/Min.±10ml/Min.
Measuring range
CO2 0~150mmHg
INSCO2 0~150mmHg
AwRR 2~150 rpm
Resolution
CO2 0.1mmHg(0~69mmHg)
0.25mmHg(70~150mmHg)
INSCO2 0.1mmHg(0~69mmHg)
0.25mmHg(70~150mmHg)
Accuracy
CO2 ±2mmHg 0~40mmHg
±5% of reading 41~70mmHg
±8% of reading 71~100mmHg
±10% of reading 101~150mmHg
AwRR ±1 rpm
Initialization Time
Mainstream Capnogram displayed in less than 15 seconds at an ambient temperature of 25℃,full specifications within 2 minutes.
Sidestream Capnogram displayed in less than 20 seconds at an ambient temperature of 25℃,full specifications within 2 minutes.
Mainstream Rise Time
Less than 60ms-Adult Reusable or Single-Patient-Use Airway Adapter
Less than 60ms-Infant Reusable or Single-Patient-Use Airway Adapter
Actualization interval about 1 Sec
Sidestream Delay Time: 2~3Sec
Alarm range
CO2 0~150 mmHg
InsCO2 0~150 mmHg
AwRR 2~150 rpm
Suffocation Alarm Delay
AwRR 10~60 Sec.
Recorder (Option)
Recall
Trend Recall
Short 1 hrs, 1 Second Resolution
Long 480 hrs, 1 Min. Resolution
Alarm Event Recall : 71 alarm events of all parameters and 8/16/32seconds of corresponding waveform.
NIBP Measurement Recall: At least 2400 NIBP measurement data
SD card
72 hrs ECG waveform
TREND review
